Series M110..M400

Horizontal Pumps

10000 - 30000 L/H

Typical applications

• Ideal for clean or slightly contaminated acids and alkalines
• Suitable for most plating solutions
• Not suitable for electroless nickel and abrasive solutions or solutions which contain ferrous particles

Features

• Magnetic drive
• Sealless, therefore leakfree
• Provide extra safety factor for agressive and expensive liquids
• Standard with GF union connetions with a choice of sockets, available in PP, PVDF and CPVC
• temp. PP 80ËšC / 176ËšF , PVDF 100ËšC / 212ËšF
• Motor with two component Polyurethane coating for excellent chemical resistance

Options

• Hose adapters
• Flanges
• Priming chamber
• Dry run protection

Downloads

Leaflet (english)
