Serie D33-D35-D39

Vertical Pumps

40000 - 180000 L/H

Typical applications
• Designed and developed for low life cycle cost in corrosive low pressure applications
• Scrubbing (fume and air)
• Waste water treatment
• Rinsing

Features
• Low energy consumption due to high hydraulic efficiency and IE3 class Premium Efficiency Motor
• Machined high grade Simona® AlphaPlus™ PP
• Elastomers EPDM
• Sealless pump, can run dry endlessly
• Round mounting plate for easy installation
• Including discharge pipe with GF union
• Impeller locked (no damage with wrong rotation direction)
• Oversized motor according to Hendor heavy duty specifications
• Stainless steel shaft and fasteners (no metal in contact with liquid)
• Motor 4 pole, IP55, Class F, S1 Duty and PTC-160
• Double layer 2C chemical resistant coating
• Hoisting eyes for easy lifting and transportation
• CE and usULc certified complying with IEC 60034 standards

Options
• GF union connection socket in PVC or CPVC
• Suction extension pipe
• Suction strainer
• FPM (Viton™) elastomers
• Vapour lock
• Foam rubber seal in mounting plate
• Flange discharge connection
• Customized mounting plate
• Customized color
• Extra anti-corrosion coating on motor
• Voltages outside standard range
